Ultrasonic Plastic Welding Machine - AN80D series
Positioning Servo Rotary Friction Welder
The AN80D Servo Rotational Friction Welding Machine combines pneumatic and electric technologies,with vertical and rotational axes working together to achieve airtight seals and precise dimensions.It is ideal for welding parts that require precise angles and height.The machine uses two servos:one for tool rotation and one for vertical movement,both with high-resolution feedback for precise control.
Application
The AN80D series friction plastic welding is suitable for high-toughness, circular thermoplastic products. It can be used in the electronics, medical, automotive industries, and various other plastic product welding applications.
Specifications
| Model:AN80D | Voltage:AC200–240V | Motion System:Servo control |
| Welding stroke:≤100mm | Process Technology:Rotational friction | Operating Device:10"color touch screen |
Main feature
- Programmable limits for advanced control.
- High-efficiency servo drive with precise positioning.
- UTC advanced processor for high-speed,precise control.
- Supports MES,DPS,DataLog,and 5G applications.
- iQS 6.0 system with multi-level password and tiered authorization.
- Smart seamless connectivity for Industry 4.0.
-
