> > > Ultrasonic Surgical Garment Sewing Machine KS05 KS10

Ultrasonic Surgical Garment Sewing Machine KS05 KS10

With an ultrasonic generator, horn vibration energy and pattern sealing wheel enable light turns of material in sealing/cutting.
Design pattern change of rollers enables sealing/cutting more quality, beautiful & strong.
Enables straight or curve sealing/cutting to meet application requirements.
Replaces & benefits over conventional stitch, needs no needle & thread. Cost down & easy operation.
No stitches prevent penetration of liquids, blood-borne particulates, provide air-water tight or water-tight barrier effect.
Optional jig can control quality and increase production speed.
Special arm design enables sealing cuff or sleeve more steadily and faster.

Materials such as non-woven fabric, polyester, nylon, thermoplastic film are suitable for processing.
Typical applications: medical surgery garments, disposable hospital gowns, surgery caps, shoe covers.
Industry use: cleanroom & laboratory use anti-dust garments, caps, gowns, air-com filter.
Living use: shower caps, car-seat covers, coat, suit-cover.

MODEL NO.	KS-05A	KS-05B	KS-10
OUTPUT POWER	1200W	1200W	1200W
FREQUENCY / ULTRASONIC SYSTEM	20KHz Continue Vibration	20KHz Continue Vibration	20KHz Continue Vibration
WELDING SPEED	0~18 m/min.	0~18 m/min.	0~15 m/min.
WELDING WIDTH	1.0 mm ~ 5.0 mm	1.0 mm ~ 10.0 mm	1.0 mm ~ 10.0 mm
LINE SOURCE	AC220V, 1P, 10A	AC220V, 1P, 10A	AC220V, 1P, 10A
AIR SOURCE REQUIRED	6 kg/cm²	6 kg/cm²	6 kg/cm²
WORKING TABLE	54 x 43 cm (Φ75mm)	18 x 40 cm (Φ90mm)	50 x 40 cm
NET WEIGHT	80 kg	50 kg	80 kg
MACHINE SIZE	135 x 64 x 127 cm	120 x 54 x 127 cm	Machine: 66 x 89 x 44 cm Control: 54 x 184 x 40 cm
THICKNESS OF MATERIAL	0.03 mm ~ 1.0 mm	0.03 mm ~ 1.0 mm	0.03 mm ~ 1.0 mm
